6357K43 Dry-Running Mounted Ball Bearings

$40.42 $62.18

Quantity:

Add to Cart

Send a Inquiry

Add to Wishlist

Product Number:

6357K43

Additional info

Mounted Bearing Type	Base Mount
Bearing Type	Ball
Housing Material	Polyester Plastic
Shaft Mount Type	Set Screw
For Shaft Diameter	3/4"
Center Height	1 21/64"
Overall Height	2 9/16"
Overall Length	5"
Overall Width	1 1/2"
Dynamic Radial Load Capacity	75 lb.
Maximum Rotation Speed	800 rpm
Bearing Material	Acetal
Bearing Seal Type	Open
Misalignment Capability	1.5°
ABEC Rating	Not Rated
Alignment Style	Self-Aligning
For Load Direction	Radial
For Shaft Type	Round
Grease Fitting Included	No
Product ID	0.75"
ID Tolerance	0" to 0.003"
Lubrication	Not Required
Maximum Temperature Rating in Liquid	120° F
Mounting Hole Hole Length	35/64"
Mounting Hole Hole Width	7/16"
Mounting Hole Hole Center to Center	3 3/4"
Mounting Hole Number of Holes	2
Mounting Hole Fasteners Included	No
Number of Set Screws Included	1
Performance	Dry Running, Moisture Resistant
Set Screw Thread Size	1/4"-20
Static Radial Load Capacity	50 lb.
System of Measurement	Inch
Temperature	-30° F to 180° F
Country of Origin	United States
DFARS Compliance	Specialty Metals COTS-Exempt
ECCN	1C999
REACH Compliance	REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant
RoHS Compliance	RoHS 3 (2015/863/EU) Compliant
Schedule B Number	848320.001
Product Description	Leave the lubricant in the supply closet— these low-maintenance bearings are made from naturally slippery plastic. They'll keep shafts spinning with no messy grease to drip off, wash out, or collect dust. The balls roll nearly friction-free within a sturdy housing to support shafts as they turn. Polyester Plastic Housing — Lightweight and naturally rust- resistant, with a smooth surface that's easy to wipe clean. Set Screw — Turn the screw to lock your shaft in place. A simple, reliable choice, set screws grip tightly, but they can mar shaft surfaces. Misalignment Capability — Bearings compensate for as much shaft misalignment as the degree listed. This extends the life of the bearing and protects against wear if shafts are slightly askew.
