5912K77
$8.01
$0.00
| Mounted Bearing Type | Two-Bolt Flange Mount |
| Bearing Type | Plain |
| Housing Material | Aluminum |
| Shaft Mount Type | Slip Fit |
| For Shaft Diameter | 3/8" |
| Overall Height | 1 1/8" |
| Overall Length | 2 1/4" |
| Overall Width | 7/16" |
| Bearing Material | 840 Bearing Bronze |
| Misalignment Capability | 5° |
| Alignment Style | Self-Aligning |
| For Load Direction | Radial |
| For Shaft Type | Round |
| Product ID | 0.3758" |
| ID Tolerance | 0" to 0.0007" |
| Lubrication | Lubricated |
| Mounting Hole Hole Center to Center | 1 3/4" |
| Mounting Hole Fasteners Included | No |
| Performance | Corrosion Resistant |
| System of Measurement | Inch |
| Temperature | -20° F to 200° F |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | EAR99 |
| REACH Compliance | REACH (EC 1907/2006) (06/27/2024, 241 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 848330.8065 |
| Flange Thickness | 3/16" |
| Mounting Hole Hole Diameter | 9/32" |
| Plain Bearing Type | Sleeve |
| Bearing Width | 27/64" |
| P Max | 2,000 psi |
| PV Max | 25,000 |
| V Max | 1,200 sfpm |
| Lubricant | Oil |
| Lubrication Method | Embedded |
| Product Description | Reduce upkeep with sleeve bearings that lubricate themselves. Made from porous, oil-saturated bronze, they release a thin film of lubrication upon startup to keep shafts spinning. With no moving parts, sleeve bearings withstand dusty, dirty environments better than ball or roller bearings. However, with more friction generated, they're less effective at high speeds. The sturdy housing supports the shaft and secures with a two-bolt flange, the most common type of flanged bearing. Aluminum Housing — One-third the weight of cast iron but not as strong. Aluminum also resists corrosion. Misalignment Capability — Bearings compensate for as much shaft misalignment as the degree listed. This extends the life of the bearing and protects against wear if shafts are slightly askew. |
