2031N14
$50.76
$0.00
| Mounted Bearing Type | Base Mount |
| Bearing Type | Roller |
| Housing Material | Aluminum |
| Shaft Mount Type | Press Fit |
| For Shaft Diameter | 12 mm |
| Center Height | 19 mm |
| Overall Height | 39.5 mm |
| Overall Length | 82.5 mm |
| Overall Width | 20 mm |
| Dynamic Radial Load Capacity | 1,100 lb. |
| Maximum Rotation Speed | 12,420 rpm |
| Bearing Material | Steel |
| Bearing Seal Type | Open |
| Misalignment Capability | 5° |
| Alignment Style | Self-Aligning |
| For Load Direction | Radial |
| For Shaft Type | Round |
| Grease Fitting Included | No |
| Product ID | 12 mm |
| ID Tolerance | -0.011 mm to 0 mm |
| Lubrication | Lubricated |
| Mounting Hole Hole Center to Center | 63.5 mm |
| Mounting Hole Number of Holes | 2 |
| Mounting Hole Fasteners Included | No |
| Static Radial Load Capacity | 1,350 lb. |
| System of Measurement | Metric |
| Temperature | -20° F to 210° F |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | EAR99 |
| REACH Compliance | REACH (EC 1907/2006) (06/27/2024, 241 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 848320.0050 |
| Mounting Hole Hole Diameter | 8.7 mm |
| Roller Bearing Type | Needle |
| Lubricant | Grease with Lithium Thickener |
| For Shaft Surface Smoothness Ra | 16 μin |
| Product Description | Slim but sturdy, needle roller bearings have a thinner profile than ball bearings. They're better than other roller bearings at handling light loads at high speeds. The solid housing bolts down to support shafts as they turn. Lubricate your bearings regularly to keep them in tip-top shape. These bearings are not sealed, which may attract dust and debris in the grease. Aluminum Housing — One-third the weight of cast iron but not as strong. Aluminum also resists corrosion. Press Fit — Mount directly onto a hardened and ground shaft. Misalignment Capability — Bearings compensate for as much shaft misalignment as the degree listed. This extends the life of the bearing and protects against wear if shafts are slightly askew. |
