1301N6 Dry-Running Flanged Ball Bearings

$9.70 $14.93

Quantity:

Add to Cart

Send a Inquiry

Add to Wishlist

Product Number:

1301N6

Additional info

For Shaft Type	Round
Bearing Construction	Single Row
Bearing Seal Type	Open
For Shaft Diameter	5/8"
For Housing ID	1 3/8"
Width	7/16"
Width Tolerance	-0.005" to 0.005"
ABEC Rating	Not Rated
Material	Acetal
Maximum Rotation Speed	1,000 rpm
Lubrication	Not Required
Temperature Range Minimum	-40° F
Temperature Range Max	180° F
Bearing Trade Number	R10
Ball Bearing Profile	Flanged
Ball Material	316 Stainless Steel
Bearing Type	Ball
Cage Material	Acetal
For Load Direction	Radial
Product ID	0.625"
ID Tolerance	0" to 0.003"
OD	1.375"
OD Tolerance	-0.004" to 0"
Performance	Dry Running, Moisture Resistant
Radial Clearance	0.001" to 0.009"
Shaft Mount Type	Press Fit
System of Measurement	Inch
Country of Origin	United States
DFARS Compliance	Specialty Metals COTS-Exempt
ECCN	1C999
REACH Compliance	REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant
RoHS Compliance	RoHS 3 (2015/863/EU) Compliant
Schedule B Number	848210.5048
Dynamic Radial Load Capacity	65 lb.
Inner Ring Type	Standard
Static Radial Load Capacity	50 lb.
Flange OD	1.5"
Flange Thk	0.06"
Product Description	Don't risk your bearing popping out of place or making a mess. The flange presses against the housing wall, so vibration and other sudden forces parallel to the shaft (thrust loads) won't knock these bearings off- kilter. Made of naturally slippery plastic, there's no lubricant to maintain. No lubricant means no oil that could drip off, wash out, or collect dust, so they're ideal for spic-and-span spaces. They stand up to thorough cleanings since they won't rust or warp from moisture. Open — With no rubber seal to block airflow, these bearings dissipate heat quickly, reducing wear and extending the life of the bearing. Acetal — The most common choice for plastic bearings, acetal is economical yet still stands up to daily wear and tear. 316 Stainless Steel Balls — Won't corrode from salt water or harsh chemicals, such as bleach and chlorine found in cleaning solutions.

35%

1301N6 Dry-Running Flanged Ball Bearings

$9.70 $14.93

Bulk orders will be discounted, please contact us.

Don't risk your bearing popping out of place or making a mess. The flange presses against the housing wall, so vibration and other sudden forces parallel to the shaft (thrust loads) won't knock these bearings off- kilter. Made of naturally slippery plastic, there's no lubricant to maintain. No lubricant means no oil that could drip off, wash out, or collect dust, so they're ideal for spic-and-span spaces. They stand up to thorough cleanings since they won't rust or warp from moisture. Open — With no rubber seal to block airflow, these bearings dissipate heat quickly, reducing wear and extending the life of the bearing. Acetal — The most common choice for plastic bearings, acetal is economical yet still stands up to daily wear and tear. 316 Stainless Steel Balls — Won't corrode from salt water or harsh chemicals, such as bleach and chlorine found in cleaning solutions.

Product Number: 1301N6

Add to Wishlist Add to Compare

SEND INQUIRY

Description

For Shaft Type	Round
Bearing Construction	Single Row
Bearing Seal Type	Open
For Shaft Diameter	5/8"
For Housing ID	1 3/8"
Width	7/16"
Width Tolerance	-0.005" to 0.005"
ABEC Rating	Not Rated
Material	Acetal
Maximum Rotation Speed	1,000 rpm
Lubrication	Not Required
Temperature Range Minimum	-40° F
Temperature Range Max	180° F
Bearing Trade Number	R10
Ball Bearing Profile	Flanged
Ball Material	316 Stainless Steel
Bearing Type	Ball
Cage Material	Acetal
For Load Direction	Radial
Product ID	0.625"
ID Tolerance	0" to 0.003"
OD	1.375"
OD Tolerance	-0.004" to 0"
Performance	Dry Running, Moisture Resistant
Radial Clearance	0.001" to 0.009"
Shaft Mount Type	Press Fit
System of Measurement	Inch
Country of Origin	United States
DFARS Compliance	Specialty Metals COTS-Exempt
ECCN	1C999
REACH Compliance	REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant
RoHS Compliance	RoHS 3 (2015/863/EU) Compliant
Schedule B Number	848210.5048
Dynamic Radial Load Capacity	65 lb.
Inner Ring Type	Standard
Static Radial Load Capacity	50 lb.
Flange OD	1.5"
Flange Thk	0.06"
Product Description	Don't risk your bearing popping out of place or making a mess. The flange presses against the housing wall, so vibration and other sudden forces parallel to the shaft (thrust loads) won't knock these bearings off- kilter. Made of naturally slippery plastic, there's no lubricant to maintain. No lubricant means no oil that could drip off, wash out, or collect dust, so they're ideal for spic-and-span spaces. They stand up to thorough cleanings since they won't rust or warp from moisture. Open — With no rubber seal to block airflow, these bearings dissipate heat quickly, reducing wear and extending the life of the bearing. Acetal — The most common choice for plastic bearings, acetal is economical yet still stands up to daily wear and tear. 316 Stainless Steel Balls — Won't corrode from salt water or harsh chemicals, such as bleach and chlorine found in cleaning solutions.
