6590N118
$402.60
$0.00
| Mounted Bearing Type | Four-Bolt Flange Mount |
| Bearing Type | Ball |
| Housing Material | Plastic |
| Shaft Mount Type | Set Screw |
| For Shaft Diameter | 1 1/4" |
| Overall Height | 4 5/8" |
| Overall Length | 4 5/8" |
| Overall Width | 1 7/8" |
| Dynamic Radial Load Capacity | Not Rated |
| Maximum Rotation Speed | 300 rpm |
| Bearing Material | 303 Stainless Steel |
| Bearing Seal Type | Sealed |
| Misalignment Capability | 3° |
| Manufacturer | McMaster-Carr Approved |
| ABEC Rating | Not Rated |
| Alignment Style | Self-Aligning |
| Environment | Food and Beverage |
| Food Industry Standard | NSF Registered H1 |
| For Load Direction | Radial |
| For Shaft Type | Round |
| Grease Fitting Included | Yes |
| Product ID | 1.25" |
| ID Tolerance | -0.0005" to 0" |
| Lubricant | Grease with Aluminum Thickener |
| Lubrication | Lubricated |
| Mounting Hole Hole Center to Center | 3 5/8" |
| Mounting Hole Fasteners Included | No |
| Number of Set Screws Included | 2 |
| Set Screw Thread Size | 5/16"-24 |
| Static Radial Load Capacity | 470 lb. |
| System of Measurement | Inch |
| Temperature | -20° F to 250° F |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | 1C999 |
| REACH Compliance | REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 848320.001 |
| Grease Fitting Thread Size | 1/4"-28 |
| Grease Fitting Thread Type | UNF |
| Includes | Closed Cap |
| Flange Thickness | 5/8" |
| Mounting Hole Hole Diameter | 1/2" |
