6455K113
$9.01
$0.00
| For Shaft Type | Round |
| Bearing Construction | Single Row |
| Bearing Seal Type | Open |
| For Shaft Diameter | 10 mm |
| For Housing ID | 28 mm |
| Width | 8 mm |
| Width Tolerance | -0.127 mm to 0.127 mm |
| ABEC Rating | Not Rated |
| Material | Acetal |
| Maximum Rotation Speed | 1,100 rpm |
| Lubrication | Not Required |
| Temperature Range Minimum | -40° F |
| Temperature Range Max | 180° F |
| Bearing Trade Number | 16100 |
| Ball Bearing Profile | Standard |
| Ball Material | 316 Stainless Steel |
| Bearing Type | Ball |
| Cage Material | Acetal |
| For Load Direction | Radial |
| Product ID | 10 mm |
| ID Tolerance | 0 mm to 0.0762 mm |
| OD | 28 mm |
| OD Tolerance | -0.1016 mm to 0 mm |
| Performance | Dry Running, Moisture Resistant |
| Radial Clearance | 0.0254 mm to 0.2286 mm |
| Shaft Mount Type | Press Fit |
| System of Measurement | Metric |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | 1C999 |
| REACH Compliance | REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 848210.5044 |
| Dynamic Radial Load Capacity | 55 lb. |
| Inner Ring Type | Standard |
| Static Radial Load Capacity | 42 lb. |
