1495N18
$731.81
$0.00
| Mounted Bearing Type | Base Mount |
| Bearing Type | Roller |
| Housing Material | Powder-Coated Cast Iron |
| Shaft Mount Type | Set Screw |
| For Shaft Diameter | 4" |
| Center Height | 4 1/4" |
| Overall Height | 8 1/2" |
| Overall Length | 15 1/4" |
| Overall Width | 6 1/4" |
| Maximum Rotation Speed | 1,500 rpm |
| Bearing Material | Steel |
| Bearing Seal Type | Sealed |
| Alignment Style | Fixed |
| For Load Direction | Combined Radial and Thrust |
| For Shaft Type | Round |
| Grease Fitting Included | Yes |
| Product ID | 4" |
| ID Tolerance | 0" to 0.002" |
| Lubrication | Lubricated |
| Mounting Hole Hole Length | 1 1/8" |
| Mounting Hole Hole Width | 7/8" |
| Mounting Hole Hole Center to Center | 12 1/2" |
| Mounting Hole Number of Holes | 4 |
| Mounting Hole Fasteners Included | No |
| Number of Set Screws Included | 4 |
| Set Screw Thread Size | 5/8"-11 |
| Static Radial Load Capacity | 154,000 lb. |
| System of Measurement | Inch |
| Temperature | -60° F to 250° F |
| Country of Origin | India |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | EAR99 |
| REACH Compliance | REACH (EC 1907/2006) (06/14/2023, 235 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 848320.005 |
| Roller Bearing Type | Tapered |
| Grease Fitting Thread Type | NPT |
| Lubricant | Grease with Lithium Thickener |
| Dynamic Load Capacity Radial | 26,900 lb. |
| Dynamic Load Capacity Thrust | 6,900 lb. |
| Grease Fitting Pipe Size | 1/8 |
| Product Description | Support heavier loads than mounted ball or needle-roller bearings, but at lower speeds. These bearings also withstand thrust loads, which are forces acting parallel to the shaft. The sturdy housing bolts down to support shafts as they turn. Lubricate your bearings regularly to keep them in tip-top shape. These bearings come packed with grease and sealed to block out dust and contaminants. Powder - Coated Cast Iron Housing — A rugged iron base coated in thick powder that protects against water, mild detergents, and oil. However, if the coating is scratched or chipped, the underlying iron may rust. Set Screw — Turn the screw to lock your shaft in place. A simple, reliable choice, set screws grip tightly, but they can mar shaft surfaces. |
